1000m OSC8 8 Core 24AWG Overall Foil Screen SWA 600V Black PE (9538) - Cable
SFX/OSC8-SWA-PE-BLK-1000
£1,819.01 inc. VAT
£1,515.84 ex. VAT
Available in 4-5 business days
-
1000m OSC8 8 Core 24AWG Overall Foil Screen SWA 600V Black PE (9538) CPR:Fca
- Additional screening makes this cable suitable to be installed in areas where protection from electrical interferance is required
- Used for RS232 protocol
- Polyethylene plastic is excellent for use externally above ground or below ground inside ducting
- Provides mechanical protection against cable being pinched or pierced
- UV resistant
- Can be cut to any length required saving instillation time
- Brand
- Securi-Flex
- Guarantee
- 25 Years
- Category
- Belden Equivalents
- Product Code
- SFX/OSC8-SWA-PE-BLK-1000
- Size
- Reel of 1000m
- Dimensions
- Overall Diameter (mm): 9.60 ±0.20, Conductor Diameter (mm): 0.20 ±0.008 x 7(0.22mm²), Insulation Thickness (mm): 0.29, Insulation Thickness 2 (mm): 1.15 ±0.10, Stranded Diameter (mm): 0.22, Drain Wire Conductor Diameter (mm): 0.20 ±0.008 x 7
- Main Colour
- Black
- Weight
- 245 g
- GTIN
- 5056631505563
-
